- Philips: MIFARE®, DESFire®, MIFARE® ProX®,
SMART MX, and i.code
- HID: iCLASS®
- Texas Instruments: TagIT®
- ST Micro: x-ident, SR 176, SR 1X 4K
- Infineon: My-d (in secure mode UID only)
- Atmel: AT088RF020
- KSW MicroTech: KSW TempSens
- JCOP in RSA mode
|
 |
- Dimensions - 120.5 mm (L) x 72 mm (W) x 20.4 mm (H)
- Weight - 150g
- Interface - USB 2.0 Full Speed
- Operating Distance - Up to 50 mm (depends on the tag type)
- Supply Voltage - Regulated 5 V DC
- Supply Current - 200mA (max); 100mA (normal)
- Operating Temperature : 0-50°C
- Humidity : 10 - 80 %
- Operating Frequency : 13.56MHz
- Smart Card Interface Support
ISO14443 T=CL for ISO 14443 A & B Parts 1-4 compliant cards and T=CL Emulation for MIFARE® series, NFC reader mode
Memory card support is made upon request
- Compliance / Certifications - Germany nPA certified, PC/SC, CCID, CE, FCC, RoHS Compliant, Microsoft WHQL: 2000, XP, Vista, 7
- Operating System Support
Win 2000, Win 2003, Win 2003 R2, Win XP, Win Vista, Win 2008, Win 7
Win 2003 x64, Win XP x64, Win Vista x64, Win 2008 x64, Win 2008 R2 x64, Win 7 x64
|
